Displacement 149.5ml
Engine 1 Cylinder,4 stroke
Bore & Stroke 63.5×47.2mm
Cooling System Air Cooled
Compression Ratio 9.2:1
Fuel feed 90#
Max Power( Kw/rpm) 9.1/8000
Max Torque(N.M/rpm)  11.6/7000
Max Speed 90 kmph
Ground clearance 150 mm
Fuel consumption 2.2L/100KM
Ignition CDI
Transmission chain
Fuel tank capacity 12L
Starting System Electric+kick start
Front Brakes Disc brake
Rear Brake Drum brake
Front suspension hydraulic suspension
Rear suspension hydraulic suspension
Front wheels Alum 3.00-18
Rear wheels Alum 110/90-16
Wheel Base 1370 mm
Payload 150kg
Net Weight 118kg
Gross Weight 138kg
Packing type steel+carton
Packing size  1800*460*860mm
20FT quantity 30 units
40HQ quantity 96units
