Displacement 149.5ml
Engine Single Cylinder, 4 Stroke
Bore & Stroke 62×49.5
Cooling System Air Cooled
Compression Ratio 9.1:1
Fuel feed 90#
Max Power( Kw/rpm) 8.5/8500
Max Torque(N.M/rpm)  8.7/7000
Max Speed 85 kmph
Ground clearance 120 mm
Ignition 2.2L/100KM
Fuel consumption CDI
Transmission Chain
Fuel tank capacity 9L
Starting System Electric+kick start
Front Brakes Drum brake
Rear Brake Drum brake
Front suspension Hydraulic Suspension
Rear suspension Hydraulic Suspension
Front wheels spoke 2.75-18
Rear wheels spoke 3.00-18
Wheel Base 1370 mm
Payload 150kg
Net Weight 115kg
Gross Weight 135kg
Packing type Steel + Carton
Packing size  1650*380*860mm
20FT quantity 40units
40HQ quantity 129units
