Displacement 124ml
Engine 1 Cylinder, 4 Stroke
Bore & Stroke 56.6×49.5
Cooling System Air Cooled
Compression Ratio 9.1:1
Fuel feed 90#
Max Power( Kw/rpm) 7.0/7800
Max Torque(N.M/rpm)  8.2/7500
Max Speed 80kmph
Ground clearance 120mm
Ignition CDI
Fuel consumption 2.1L/KM
Transmission Chain
Fuel tank capacity 9L
Starting System Electric+kick start
Front Brakes Drum brake
Rear Brake Drum brake
Front suspension Hydraulic Suspension
Rear suspension Hydraulic Suspension
Front wheels spoke 2.75-18
Rear wheels spoke 3.00-18
Wheel Base 1310mm
Payload 150kg
Net Weight 115kg
Gross Weight 135kg
Packing type Steel + Carton
Packing size  1650*380*860mm
20FT quantity 40units
40HQ quantity 129units
